MU Single Mode Ferrule with Flange – MT2039

Renderings

View LargerDownload Technical Drawing

Specifications

Model MT2039 w/flange
Inside Diameter 0.126 - 0.127
Outside Diameter 1.25
Length 6.45 - 6.55
Type Zirconia
Custom options are available.

Description

  • Available in single-mode or multi-mode ID sizes with 1.2485/1.2495mm OD x 6.45/6.55mm Length
  • Single-mode standard sizes include: .1250mm ID, .1255mm ID and .1260mm ID (1um tolerances)
  • Multi-mode standard sizes include: .1260mm ID and .1270mm ID (4um tolerances)
  • Custom ID, OD and Lengths available upon customer request
  • Available in zirconia or alumina ceramic material
